Zehnder Yucca Asym Double Towel Rail
Zehnder Yucca Asym Double Towel Rail
Zehnder Yucca Asym Double Towel Rail

Is dual energy for you?

Zehnder and Bisque radiators can be fitted with dual energy heating options to continue to offer warmth and comfort throughout the home during summer months when the central heating system is not in use.

To make your radiator work in this manner, in addition to your towel rail you will need valves and an electric element with controls.

The element will be fitted on the ‘return’ side of vertical tubes on either side of the towel rail. This is the side the water flows out from, not into, the towel rail. If you need to identify this, please talk with your installer.

Depending on your chosen towel rail the valves may be able to be installed in the central connection points if your towel rail has these. This simplifies the installation as the element and valves are separated.

If your rail does not have central connections, it will need to be fitted with valves that can accommodate the element, like this:

or, via a ‘T’ piece which offsets the pipework like this:

Switch off the central heating

Vent the radiator to ensure there isn’t any air present

Close the flow valve (only)

Activate the immersion heater as required

De-activate the immersion heater

Open the flow valve

The immersion heater should be fitted on the ‘return’ side of the radiator.

Simultaneous use of the electrical element and the central heating should be avoided as this will shorten the life of the element and invalidate the warranty.

We recommend that all electrical work be undertaken in accordance with current I.E.E wiring regulations. If in doubt of zoning requirements, we recommend that a 30mA R.C.D is installed.

'Dual energy' units are designed to be used for occasional heating i.e. Summer when it is a cool evening, the main heating is off but you would like to heat the bathroom only. In this situation you would use the electric element for a few hours and turn off.

If you require electricity only, then an additional heating element is not suitable – please choose an electric towel rail.

Zehnder Yucca Asym Double Towel Rail

Regular price
£464.12
Sale price
£464.12
Include VAT Delivery Terms, options selected at checkout.

Delivery:
25- 30 working days
Guarantee - 5 Years
Electrical - 2 Years
Heat output @ ΔT=50K:
325/2133 - 1151/3927 Watts/BTU
Electric Immersion Rating:
400 - 750 Watts

SKU: YAD-130-040
White / 1304x378 (YAD-130-040) 31753160654948
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1304mm
Weight: 19.7kg
Delta 50 Watts: 625
Delta 50 BTU: 2133
Postition: Vertical
White / 1304x578 (YAD-130-060) 31753160687716
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1304mm
Weight: 28.9kg
Delta 50 Watts: 880
Delta 50 BTU: 3003
Postition: Vertical
White / 1736x378 (YAD-170-040) 31753160720484
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1736mm
Weight: 26.2kg
Delta 50 Watts: 832
Delta 50 BTU: 2838
Postition: Vertical
White / 1736x478 (YAD-170-050) 31753160753252
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 1736mm
Weight: 32.3kg
Delta 50 Watts: 995
Delta 50 BTU: 3395
Postition: Vertical
White / 1736x578 (YAD-170-060) 31753160786020
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1736mm
Weight: 38.4kg
Delta 50 Watts: 1151
Delta 50 BTU: 3927
Postition: Vertical
Custom Colour / 1304x378 (YAD-130-040-CF) 27997042573412
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1304mm
Weight: 19.7kg
Delta 50 Watts: 625
Delta 50 BTU: 2133
Postition: Vertical
Custom Colour / 1304x578 (YAD-130-060-CF) 27997047357540
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1304mm
Weight: 28.9kg
Delta 50 Watts: 880
Delta 50 BTU: 3003
Postition: Vertical
Custom Colour / 1736x378 (YAD-170-040-CF) 27997051551844
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1736mm
Weight: 26.2kg
Delta 50 Watts: 832
Delta 50 BTU: 2838
Postition: Vertical
Custom Colour / 1736x478 (YAD-170-050-CF) 27997051945060
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 1736mm
Weight: 32.3kg
Delta 50 Watts: 995
Delta 50 BTU: 3395
Postition: Vertical
Custom Colour / 1736x578 (YAD-170-060-CF) 27997054435428
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1736mm
Weight: 38.4kg
Delta 50 Watts: 1151
Delta 50 BTU: 3927
Postition: Vertical

This beautiful and practical radiator is made to order in a wide range of colours (30 working day lead-time). It is suitable for use with either the DE Pack or DBM immersion heater for continued use during the summer months when the conventional central heating system is not required and can also be installed perpendicular to the wall to create a partition.

This radiator is available in any of the Zehnder Colour System colours – see here - at a cost of the standard white + 25%. Colour swatches can be ordered here and the cost is refundable either when you return the swatch or place an order. Delivery of coloured radiators is normally c.4 weeks. Please contact us for further details.

Download PDF Spec
