Is dual energy for you?

Zehnder and Bisque radiators can be fitted with dual energy heating options to continue to offer warmth and comfort throughout the home during summer months when the central heating system is not in use.

To make your radiator work in this manner, in addition to your towel rail you will need valves and an electric element with controls.

The element will be fitted on the ‘return’ side of vertical tubes on either side of the towel rail. This is the side the water flows out from, not into, the towel rail. If you need to identify this, please talk with your installer.

Depending on your chosen towel rail the valves may be able to be installed in the central connection points if your towel rail has these. This simplifies the installation as the element and valves are separated.

If your rail does not have central connections, it will need to be fitted with valves that can accommodate the element, like this:

or, via a ‘T’ piece which offsets the pipework like this:

Switch off the central heating

Vent the radiator to ensure there isn’t any air present

Close the flow valve (only)

Activate the immersion heater as required

De-activate the immersion heater

Open the flow valve

The immersion heater should be fitted on the ‘return’ side of the radiator.

Simultaneous use of the electrical element and the central heating should be avoided as this will shorten the life of the element and invalidate the warranty.

We recommend that all electrical work be undertaken in accordance with current I.E.E wiring regulations. If in doubt of zoning requirements, we recommend that a 30mA R.C.D is installed.

'Dual energy' units are designed to be used for occasional heating i.e. Summer when it is a cool evening, the main heating is off but you would like to heat the bathroom only. In this situation you would use the electric element for a few hours and turn off.

If you require electricity only, then an additional heating element is not suitable – please choose an electric towel rail.

Zehnder Yucca Asym

Regular price
£221.55
Sale price
£221.55
Include VAT Delivery Terms, options selected at checkout.

Delivery:
Chrome - 5 -7 working days

White/Non Stock Colours & Finishes - 25- 30 working days
Guarantee 5 Years
Heat output @
 ΔT=50K:
351 - 795
Watts
1197 - 2711 BTU
Max Immersion Rating - 150 - 500 Watts

SKU: YA-090-050
White / 872x478 (YA-090-050) 31753118056548
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 872mm
Weight: 9.2kg
Delta 50 Watts: 353
Delta 50 BTU: 1204
Postition: Vertical
White / 1304x378 (YA-130-040) 31753118089316
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1304mm
Weight: 11.3kg
Delta 50 Watts: 439
Delta 50 BTU: 1498
Postition: Vertical
White / 1304x478 (YA-130-050) 31753118122084
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 1304mm
Weight: 13.6kg
Delta 50 Watts: 525
Delta 50 BTU: 1791
Postition: Vertical
White / 1304x578 (YA-130-060) 31753118154852
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1304mm
Weight: 15.9kg
Delta 50 Watts: 607
Delta 50 BTU: 2071
Postition: Vertical
White / 1736x378 (YA-170-040) 31753118187620
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1736mm
Weight: 15.0kg
Delta 50 Watts: 574
Delta 50 BTU: 1958
Postition: Vertical
White / 1736x478 (YA-170-050) 31753118220388
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 1736mm
Weight: 18.1kg
Delta 50 Watts: 696
Delta 50 BTU: 2375
Postition: Vertical
White / 1736x578 (YA-170-060) 31753118253156
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1736mm
Weight: 21.1kg
Delta 50 Watts: 798
Delta 50 BTU: 2723
Postition: Vertical
Chrome / 872x478 (YAC-090-050) 31753118285924
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 872mm
Weight: 9.2kg
Delta 50 Watts: 247
Delta 50 BTU: 842
Postition: Vertical
Chrome / 1304x378 (YAC-130-040) 31753118318692
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1304mm
Weight: 11.3kg
Delta 50 Watts: 307
Delta 50 BTU: 1047
Postition: Vertical
Chrome / 1304x478 (YAC-130-050) 31753118351460
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 1304mm
Weight: 13.6kg
Delta 50 Watts: 367
Delta 50 BTU: 1254
Postition: Vertical
Chrome / 1304x578 (YAC-130-060) 31753118384228
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1304mm
Weight: 15.9kg
Delta 50 Watts: 424
Delta 50 BTU: 1447
Postition: Vertical
Chrome / 1736x378 (YAC-170-040) 31753118416996
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1736mm
Weight: 15.0kg
Delta 50 Watts: 402
Delta 50 BTU: 1372
Postition: Vertical
Chrome / 1736x478 (YAC-170-050) 31753118482532
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 1736mm
Weight: 18.1kg
Delta 50 Watts: 487
Delta 50 BTU: 1662
Postition: Vertical
Chrome / 1736x578 (YAC-170-060) 31753118515300
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1736mm
Weight: 21.1kg
Delta 50 Watts: 559
Delta 50 BTU: 1907
Postition: Vertical
Custom Colour / 872x478 (YA-090-050-CF) 27997011574884
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 872mm
Weight: 9.2kg
Delta 50 Watts: 353
Delta 50 BTU: 1204
Postition: Vertical
Custom Colour / 1304x378 (YA-130-040-CF) 27997012033636
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1304mm
Weight: 11.3kg
Delta 50 Watts: 439
Delta 50 BTU: 1498
Postition: Vertical
Custom Colour / 1304x478 (YA-130-050-CF) 27997015801956
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 1304mm
Weight: 13.6kg
Delta 50 Watts: 525
Delta 50 BTU: 1791
Postition: Vertical
Custom Colour / 1304x578 (YA-130-060-CF) 27997016031332
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1304mm
Weight: 15.9kg
Delta 50 Watts: 607
Delta 50 BTU: 2071
Postition: Vertical
Custom Colour / 1736x378 (YA-170-040-CF) 27997020323940
Radiator Type: Dual Fuel
Immersion Rating:
Width: 378mm
Height: 1736mm
Weight: 15.0kg
Delta 50 Watts: 574
Delta 50 BTU: 1958
Postition: Vertical
Custom Colour / 1736x478 (YA-170-050-CF) 27997022650468
Radiator Type: Dual Fuel
Immersion Rating:
Width: 478mm
Height: 1736mm
Weight: 18.1kg
Delta 50 Watts: 696
Delta 50 BTU: 2375
Postition: Vertical
Custom Colour / 1736x578 (YA-170-060-CF) 27997024452708
Radiator Type: Dual Fuel
Immersion Rating:
Width: 578mm
Height: 1736mm
Weight: 21.1kg
Delta 50 Watts: 798
Delta 50 BTU: 2723
Postition: Vertical

The Zehnder Yucca where great design meets practicality. Available in chrome and white The Zehnder Yucca is available in a wide range of sizes and heat outputs and can also be configured with the Zehnder Room Divider Bracket. For those needing higher heat output the Zehnder Yucca Asym double tube version is available. Dimension ranges from 872mm x 478mm to 1736mm x 578mm.

This radiator is available in any of the Zehnder Colour System colours – see here - at a cost of the standard white + 25%. Colour swatches can be ordered here and the cost is refundable either when you return the swatch or place an order. Delivery of coloured radiators is normally c.4 weeks. Please contact us for further details.

Download PDF Spec
