Is dual energy for you?

Zehnder and Bisque radiators can be fitted with dual energy heating options to continue to offer warmth and comfort throughout the home during summer months when the central heating system is not in use.

To make your radiator work in this manner, in addition to your towel rail you will need valves and an electric element with controls.

The element will be fitted on the ‘return’ side of vertical tubes on either side of the towel rail. This is the side the water flows out from, not into, the towel rail. If you need to identify this, please talk with your installer.

Depending on your chosen towel rail the valves may be able to be installed in the central connection points if your towel rail has these. This simplifies the installation as the element and valves are separated.

If your rail does not have central connections, it will need to be fitted with valves that can accommodate the element, like this:

or, via a ‘T’ piece which offsets the pipework like this:

Switch off the central heating

Vent the radiator to ensure there isn’t any air present

Close the flow valve (only)

Activate the immersion heater as required

De-activate the immersion heater

Open the flow valve

The immersion heater should be fitted on the ‘return’ side of the radiator.

Simultaneous use of the electrical element and the central heating should be avoided as this will shorten the life of the element and invalidate the warranty.

We recommend that all electrical work be undertaken in accordance with current I.E.E wiring regulations. If in doubt of zoning requirements, we recommend that a 30mA R.C.D is installed.

'Dual energy' units are designed to be used for occasional heating i.e. Summer when it is a cool evening, the main heating is off but you would like to heat the bathroom only. In this situation you would use the electric element for a few hours and turn off.

If you require electricity only, then an additional heating element is not suitable – please choose an electric towel rail.

Zehnder Stellar Spa Cloakroom Towel Rail

Regular price
£216.06
Sale price
£216.06
Include VAT Delivery Terms, options selected at checkout.

Delivery:
Stainless Steel 5 -7 working days
Painted 25 - 30 working days
Guarantee 10 Years
Heat output @ ΔT=50K
161 - 517 Watts
549 - 1764 BTU
Max Immersion 100 - 300W

SKU: STGI-060-045
Stainless Steel / 572x450 (STGI-060-045) 31753120710756
Radiator Type: Dual Fuel
Immersion Rating:
Width: 450mm
Height: 572mm
Weight: 3.1kg
Delta 50 Watts: 161
Delta 50 BTU: 549
Postition: Vertical
Stainless Steel / 788x300 (STGI-080-030) 31753120743524
Radiator Type: Dual Fuel
Immersion Rating:
Width: 300mm
Height: 788mm
Weight: 3.4kg
Delta 50 Watts: 171
Delta 50 BTU: 583
Postition: Vertical
Custom Colour / 572x450 (STGI-060-045-CF) 27959389323364
Radiator Type: Dual Fuel
Immersion Rating:
Width: 450mm
Height: 572mm
Weight: 3.1kg
Delta 50 Watts: 161
Delta 50 BTU: 549
Postition: Vertical
Custom Colour / 788x300 (STGI-080-030-CF) 27959390240868
Radiator Type: Dual Fuel
Immersion Rating:
Width: 300mm
Height: 788mm
Weight: 3.4kg
Delta 50 Watts: 171
Delta 50 BTU: 583
Postition: Vertical

The Zehnder Stellar Cloakroom is an attractive choice for small spaces and is either available in long lasting polished stainless steel from stock or contact us on 01892 600171 to discuss painted finishes. Simply elegant, simply ideal for minimalist bathrooms, Zehnder Stellar Spa combines minimalist design with maximum functionality. Large spaces between the tubes are the perfect space for hanging towels. The Stellar Spa comes complete with a 10 year warranty.

This radiator is available in any of the Zehnder Colour System colours – see here - at a cost of the standard white + 25%. Colour swatches can be ordered here and the cost is refundable either when you return the swatch or place an order. Delivery of coloured radiators is normally c.4 weeks. Please contact us for further details.

Download PDF Spec
