The Zehnder Charleston radiator has played a key part in the Company’s success over the past 80 years.

Continuous advances in the quality of production methods and technology has kept the Charleston Multi-column at the forefront of the radiator market.

Take a look behind the scenes to discover how they are made.

High quality, using the latest technology and production methods

This is how the famous Zehnder Charleston Multi-column is made

During the first phase of production of a multi-column radiator, steel strips are wound into a coil measuring 1200mm to 1500mm in diameter and weighing over 2 tonnes. Steel tubes measuring 4 to 6 metres are used to create the radiator columns.

Production of the collector

The coils of steel are punched by a press to create the two halves of the collector. The two pieces are then welded together to form double-machined heads. These headers are then sanded and cut in half to create two collectors. These elements are then quality checked before moving onto the next stage.

Production of the section

The collectors and the tubes are now welded together and then ground to make neat joins. At each stage the sections are checked and quality controlled.

The sections are hermetically sealed and then immersed in a bath of water. Each section is then subjected to a pressure of 16 bar to check for leaks.

Assembly

The radiator sections are now connected to each other using tip-welding. Further testing then checks each radiator for leaks.

After testing, the radiator is suspended ready for the next stage in production.

The finishing touches

First of all the radiators are cleaned to remove any dust and grease. Next a base coat is applied using an electrophoretic technique in order to protect against corrosion and to give a perfect base. The radiator is then placed into a furnace, baking the primer on to the steel at about 180°C.

After sufficient cooling, the radiator is moved along the production line ready for powder coating. Powder coating is much more environmentally friendly than wet painting. Standard white radiators are automatically painted, whereas all other colours and finishes are manually sprayed.

The radiator is then returned to the oven where the powder melts evenly and gives the radiator a perfect finish that is resistant to shock and heat.

Before packing, each radiator is thoroughly quality checked once again and then up to 98% of radiators are packaged and wrapped using a fully automated system.

Zehnder Metropolitan Vertical

Regular price
£324.23
Sale price
£324.23
Include VAT Delivery Terms, options selected at checkout.

Delivery: 25 - 30 working days Guarantee 5 Years Heat output @ ΔT=50K 405 - 1037 Watts 1382 - 3538 BTU
SKU: MEV-150-030
White / 1500x280 (MEV-150-030) 27652654432356
Radiator Type: Central Heating
Immersion Rating:
Width: 280mm
Height: 1500mm
Weight: 9.5kg
Delta 50 Watts: 405
Delta 50 BTU: 1382
Postition: Vertical
White / 1500x385 (MEV-150-040) 27652654465124
Radiator Type: Central Heating
Immersion Rating:
Width: 385mm
Height: 1500mm
Weight: 12.3kg
Delta 50 Watts: 533
Delta 50 BTU: 1819
Postition: Vertical
White / 1500x490 (MEV-150-050) 27652654497892
Radiator Type: Central Heating
Immersion Rating:
Width: 490mm
Height: 1500mm
Weight: 6.6kg
Delta 50 Watts: 655
Delta 50 BTU: 2235
Postition: Vertical
White / 1500x595 (MEV-150-060) 27652654530660
Radiator Type: Central Heating
Immersion Rating:
Width: 595mm
Height: 1500mm
Weight: 17.9kg
Delta 50 Watts: 773
Delta 50 BTU: 2637
Postition: Vertical
White / 1800x280 (MEV-180-030) 27652654104676
Radiator Type: Central Heating
Immersion Rating:
Width: 280mm
Height: 1800mm
Weight: 11.3kg
Delta 50 Watts: 490
Delta 50 BTU: 1672
Postition: Vertical
White / 1800x385 (MEV-180-040) 27652654137444
Radiator Type: Central Heating
Immersion Rating:
Width: 385mm
Height: 1800mm
Weight: 14.6kg
Delta 50 Watts: 643
Delta 50 BTU: 2194
Postition: Vertical
White / 1800x490 (MEV-180-050) 27652654170212
Radiator Type: Central Heating
Immersion Rating:
Width: 490mm
Height: 1800mm
Weight: 17.9kg
Delta 50 Watts: 791
Delta 50 BTU: 2699
Postition: Vertical
White / 1800x595 (MEV-180-060) 27652654202980
Radiator Type: Central Heating
Immersion Rating:
Width: 595mm
Height: 1800mm
Weight: 21.3kg
Delta 50 Watts: 934
Delta 50 BTU: 3187
Postition: Vertical
White / 2000x385 (MEV-200-040) 27652654334052
Radiator Type: Central Heating
Immersion Rating:
Width: 385mm
Height: 2000mm
Weight: 16.1kg
Delta 50 Watts: 714
Delta 50 BTU: 2436
Postition: Vertical
White / 2000x490 (MEV-200-050) 27652654366820
Radiator Type: Central Heating
Immersion Rating:
Width: 490mm
Height: 2000mm
Weight: 19.8kg
Delta 50 Watts: 878
Delta 50 BTU: 2996
Postition: Vertical
White / 2000x595 (MEV-200-060) 27652654399588
Radiator Type: Central Heating
Immersion Rating:
Width: 595mm
Height: 2000mm
Weight: 23.5kg
Delta 50 Watts: 1037
Delta 50 BTU: 3538
Postition: Vertical
White / 2000x280 (MEV-200-030) 27652654563428
Radiator Type: Central Heating
Immersion Rating:
Width: 280mm
Height: 2000mm
Weight: 12.5kg
Delta 50 Watts: 544
Delta 50 BTU: 1856
Postition: Vertical
Volcanic / 1800x280 (MEV-180-030-0336) 27652654235748
Radiator Type: Central Heating
Immersion Rating:
Width: 280mm
Height: 1800mm
Weight: 11.3kg
Delta 50 Watts: 490
Delta 50 BTU: 1672
Postition: Vertical
Volcanic / 1800x385 (MEV-180-040-0336) 27652654268516
Radiator Type: Central Heating
Immersion Rating:
Width: 385mm
Height: 1800mm
Weight: 14.6kg
Delta 50 Watts: 643
Delta 50 BTU: 2194
Postition: Vertical
Volcanic / 1800x490 (MEV-180-050-0336) 27652654301284
Radiator Type: Central Heating
Immersion Rating:
Width: 490mm
Height: 1800mm
Weight: 17.9kg
Delta 50 Watts: 791
Delta 50 BTU: 2699
Postition: Vertical
Custom Colour / 1500x280 (MEV-150-030-CF) 31825824317540
Radiator Type: Central Heating
Immersion Rating:
Width: 280mm
Height: 1500mm
Weight: 9.5kg
Delta 50 Watts: 405
Delta 50 BTU: 1382
Postition: Vertical
Custom Colour / 1500x385 (MEV-150-040-CF) 31825824415844
Radiator Type: Central Heating
Immersion Rating:
Width: 385mm
Height: 1500mm
Weight: 12.3kg
Delta 50 Watts: 533
Delta 50 BTU: 1819
Postition: Vertical
Custom Colour / 1500x490 (MEV-150-050-CF) 31825824448612
Radiator Type: Central Heating
Immersion Rating:
Width: 490mm
Height: 1500mm
Weight: 6.6kg
Delta 50 Watts: 655
Delta 50 BTU: 2235
Postition: Vertical
Custom Colour / 1500x595 (MEV-150-060-CF) 31825824481380
Radiator Type: Central Heating
Immersion Rating:
Width: 595mm
Height: 1500mm
Weight: 17.9kg
Delta 50 Watts: 773
Delta 50 BTU: 2637
Postition: Vertical
Custom Colour / 1800x280 (MEV-180-030-CF) 31825824645220
Radiator Type: Central Heating
Immersion Rating:
Width: 280mm
Height: 1800mm
Weight: 11.3kg
Delta 50 Watts: 490
Delta 50 BTU: 1672
Postition: Vertical
Custom Colour / 1800x385 (MEV-180-040-CF) 31825824776292
Radiator Type: Central Heating
Immersion Rating:
Width: 385mm
Height: 1800mm
Weight: 14.6kg
Delta 50 Watts: 643
Delta 50 BTU: 2194
Postition: Vertical
Custom Colour / 1800x490 (MEV-180-050-CF) 31825824907364
Radiator Type: Central Heating
Immersion Rating:
Width: 490mm
Height: 1800mm
Weight: 17.9kg
Delta 50 Watts: 791
Delta 50 BTU: 2699
Postition: Vertical
Custom Colour / 1800x595 (MEV-180-060-CF) 31825825169508
Radiator Type: Central Heating
Immersion Rating:
Width: 595mm
Height: 1800mm
Weight: 21.3kg
Delta 50 Watts: 934
Delta 50 BTU: 3187
Postition: Vertical
Custom Colour / 2000x385 (MEV-200-040-CF) 31825825202276
Radiator Type: Central Heating
Immersion Rating:
Width: 385mm
Height: 2000mm
Weight: 16.1kg
Delta 50 Watts: 714
Delta 50 BTU: 2436
Postition: Vertical
Custom Colour / 2000x490 (MEV-200-050-CF) 31825825235044
Radiator Type: Central Heating
Immersion Rating:
Width: 490mm
Height: 2000mm
Weight: 19.8kg
Delta 50 Watts: 878
Delta 50 BTU: 2996
Postition: Vertical
Custom Colour / 2000x595 (MEV-200-060-CF) 31825825267812
Radiator Type: Central Heating
Immersion Rating:
Width: 595mm
Height: 2000mm
Weight: 23.5kg
Delta 50 Watts: 1037
Delta 50 BTU: 3538
Postition: Vertical
Custom Colour / 2000x280 (MEV-200-030-CF) 31825825366116
Radiator Type: Central Heating
Immersion Rating:
Width: 280mm
Height: 2000mm
Weight: 12.5kg
Delta 50 Watts: 544
Delta 50 BTU: 1856
Postition: Vertical

The Zehnder Metropolitan Vertical is a modern, stylish and elegant interpretation of the traditional radiator.  It is stocked in a white or volcanic finish in 1800mm high varients but is also available in other colours – please contact us on 01892 600171 to discuss your requirements.  All 2000mm high versions are subject to a 25-30 day leadtime.

This radiator is available in any of the Zehnder Colour System colours – see here - at a cost of the standard white + 25%. Colour swatches can be ordered here and the cost is refundable either when you return the swatch or place an order. Delivery of coloured radiators is normally c.4 weeks. Please contact us for further details.

Download PDF Spec
