Is dual energy for you?

Zehnder and Bisque radiators can be fitted with dual energy heating options to continue to offer warmth and comfort throughout the home during summer months when the central heating system is not in use.

To make your radiator work in this manner, in addition to your towel rail you will need valves and an electric element with controls.

The element will be fitted on the ‘return’ side of vertical tubes on either side of the towel rail. This is the side the water flows out from, not into, the towel rail. If you need to identify this, please talk with your installer.

Depending on your chosen towel rail the valves may be able to be installed in the central connection points if your towel rail has these. This simplifies the installation as the element and valves are separated.

If your rail does not have central connections, it will need to be fitted with valves that can accommodate the element, like this:

or, via a ‘T’ piece which offsets the pipework like this:

Switch off the central heating

Vent the radiator to ensure there isn’t any air present

Close the flow valve (only)

Activate the immersion heater as required

De-activate the immersion heater

Open the flow valve

The immersion heater should be fitted on the ‘return’ side of the radiator.

Simultaneous use of the electrical element and the central heating should be avoided as this will shorten the life of the element and invalidate the warranty.

We recommend that all electrical work be undertaken in accordance with current I.E.E wiring regulations. If in doubt of zoning requirements, we recommend that a 30mA R.C.D is installed.

'Dual energy' units are designed to be used for occasional heating i.e. Summer when it is a cool evening, the main heating is off but you would like to heat the bathroom only. In this situation you would use the electric element for a few hours and turn off.

If you require electricity only, then an additional heating element is not suitable – please choose an electric towel rail.

Zehnder Ax Spa Towel Rail

Regular price
£152.90
Sale price
£152.90
Include VAT Delivery Terms, options selected at checkout.

Delivery:
White (except ZA-060-100/060-120)/Volcanic, Beige Quartz & Brown Quartz (ZA-048-040/060-080/060-090 sizes only)/Chrome (ZA-080-050/120-050/120/060/150-040/150-050/180-050 sizes only)- 5 -7 working days

Non Stock Sizes/Colours: 25- 30 working days
Guarantee 5 Years
Heat output @
 ΔT=50K:
230- 1485 Watts

785 - 5067 BTU

SKU: ZA-048-040
White / 484x400 (ZA-048-040) 31753148989540
Radiator Type: Dual Fuel
Immersion Rating:
Width: 400mm
Height: 484mm
Weight: 4.5kg
Delta 50 Watts: 230
Delta 50 BTU: 785
Postition: Vertical
White / 575x800 (ZA-060-080) 31753149022308
Radiator Type: Dual Fuel
Immersion Rating:
Width: 800mm
Height: 575mm
Weight: 10.2kg
Delta 50 Watts: 458
Delta 50 BTU: 1563
Postition: Horizontal
White / 575x900 (ZA-060-090) 31753149055076
Radiator Type: Dual Fuel
Immersion Rating:
Width: 900mm
Height: 575mm
Weight: 11.3kg
Delta 50 Watts: 515
Delta 50 BTU: 1757
Postition: Horizontal
White / 575x1000 (ZA-060-100) 31753149120612
Radiator Type: Dual Fuel
Immersion Rating:
Width: 1000mm
Height: 575mm
Weight: 12.4kg
Delta 50 Watts: 573
Delta 50 BTU: 1955
Postition: Horizontal
White / 575x1200 (ZA-060-120) 31753149153380
Radiator Type: Dual Fuel
Immersion Rating:
Width: 1200mm
Height: 575mm
Weight: 14.5kg
Delta 50 Watts: 687
Delta 50 BTU: 2344
Postition: Horizontal
White / 836x500 (ZA-080-050) 31753149186148
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 836mm
Weight: 8.6kg
Delta 50 Watts: 427
Delta 50 BTU: 1457
Postition: Vertical
White / 1188x500 (ZA-120-050) 31753149218916
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1188mm
Weight: 12kg
Delta 50 Watts: 586
Delta 50 BTU: 1999
Postition: Vertical
White / 1188x600 (ZA-120-060) 31753149251684
Radiator Type: Dual Fuel
Immersion Rating:
Width: 600mm
Height: 1188mm
Weight: 13.7kg
Delta 50 Watts: 685
Delta 50 BTU: 2337
Postition: Vertical
White / 1540x400 (ZA-150-040) 31753149284452
Radiator Type: Dual Fuel
Immersion Rating:
Width: 400mm
Height: 1540mm
Weight: 12.3kg
Delta 50 Watts: 614
Delta 50 BTU: 2095
Postition: Vertical
White / 1540x500 (ZA-150-050) 31753149317220
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1540mm
Weight: 14.4kg
Delta 50 Watts: 738
Delta 50 BTU: 2518
Postition: Vertical
White / 1804x500 (ZA-180-050) 31753149349988
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1804mm
Weight: 18.6kg
Delta 50 Watts: 884
Delta 50 BTU: 3016
Postition: Vertical
Chrome / 836x500 (ZAC-080-050) 31753149677668
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 836mm
Weight: 8.6kg
Delta 50 Watts: 427
Delta 50 BTU: 1457
Postition: Vertical
Chrome / 1188x500 (ZAC-120-050) 31753149710436
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1188mm
Weight: 12kg
Delta 50 Watts: 586
Delta 50 BTU: 1999
Postition: Vertical
Chrome / 1188x600 (ZAC-120-060) 31753149743204
Radiator Type: Dual Fuel
Immersion Rating:
Width: 600mm
Height: 1188mm
Weight: 13.7kg
Delta 50 Watts: 685
Delta 50 BTU: 2337
Postition: Vertical
Chrome / 1540x400 (ZAC-150-040) 31753149775972
Radiator Type: Dual Fuel
Immersion Rating:
Width: 400mm
Height: 1540mm
Weight: 12.3kg
Delta 50 Watts: 614
Delta 50 BTU: 2095
Postition: Vertical
Chrome / 1540x500 (ZAC-150-050) 31753149808740
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1540mm
Weight: 14.4kg
Delta 50 Watts: 738
Delta 50 BTU: 2518
Postition: Vertical
Chrome / 1804x500 (ZAC-180-050) 31753149841508
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1804mm
Weight: 18.6kg
Delta 50 Watts: 884
Delta 50 BTU: 3016
Postition: Vertical
Custom Colour / 484x400 (ZA-048-040-CF) 27948270944356
Radiator Type: Dual Fuel
Immersion Rating:
Width: 400mm
Height: 484mm
Weight: 4.5kg
Delta 50 Watts: 230
Delta 50 BTU: 785
Postition: Vertical
Custom Colour / 575x800 (ZA-060-080-CF) 27948014960740
Radiator Type: Dual Fuel
Immersion Rating:
Width: 800mm
Height: 575mm
Weight: 10.2kg
Delta 50 Watts: 458
Delta 50 BTU: 1563
Postition: Horizontal
Custom Colour / 575x900 (ZA-060-090-CF) 27948013551716
Radiator Type: Dual Fuel
Immersion Rating:
Width: 900mm
Height: 575mm
Weight: 11.3kg
Delta 50 Watts: 515
Delta 50 BTU: 1757
Postition: Horizontal
Custom Colour / 575x1000 (ZA-060-100-CF) 27948264259684
Radiator Type: Dual Fuel
Immersion Rating:
Width: 1000mm
Height: 575mm
Weight: 12.4kg
Delta 50 Watts: 573
Delta 50 BTU: 1955
Postition: Horizontal
Custom Colour / 575x1200 (ZA-060-120-CF) 27948267667556
Radiator Type: Dual Fuel
Immersion Rating:
Width: 1200mm
Height: 575mm
Weight: 14.5kg
Delta 50 Watts: 687
Delta 50 BTU: 2344
Postition: Horizontal
Custom Colour / 836x500 (ZA-080-050-CF) 27948011946084
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 836mm
Weight: 8.6kg
Delta 50 Watts: 427
Delta 50 BTU: 1457
Postition: Vertical
Custom Colour / 1188x500 (ZA-120-050-CF) 27948001820772
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1188mm
Weight: 12kg
Delta 50 Watts: 586
Delta 50 BTU: 1999
Postition: Vertical
Custom Colour / 1188x600 (ZA-120-060-CF) 27948002574436
Radiator Type: Dual Fuel
Immersion Rating:
Width: 600mm
Height: 1188mm
Weight: 13.7kg
Delta 50 Watts: 685
Delta 50 BTU: 2337
Postition: Vertical
Custom Colour / 1540x400 (ZA-150-040-CF) 27948004016228
Radiator Type: Dual Fuel
Immersion Rating:
Width: 400mm
Height: 1540mm
Weight: 12.3kg
Delta 50 Watts: 614
Delta 50 BTU: 2095
Postition: Vertical
Custom Colour / 1540x500 (ZA-150-050-CF) 27948006277220
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1540mm
Weight: 14.4kg
Delta 50 Watts: 738
Delta 50 BTU: 2518
Postition: Vertical
Custom Colour / 1804x500 (ZA-180-050-CF) 27948009095268
Radiator Type: Dual Fuel
Immersion Rating:
Width: 500mm
Height: 1804mm
Weight: 18.6kg
Delta 50 Watts: 884
Delta 50 BTU: 3016
Postition: Vertical

The Ax Spa (formerly the Altai Spa) is available in single or double tube options as well as a variety of heights if the only wall space available is under a window. It is stocked in chrome, white, beige quartz and brown quartz and volcanic. An optional immersion heater allows the radiator to continue to offer warmth and comfort throughout the summer months when the central heating system is not in use (single tube models only).

This radiator is available in any of the Zehnder Colour System colours – see here - at a cost of the standard white + 25%. Colour swatches can be ordered here and the cost is refundable either when you return the swatch or place an order. Delivery of coloured radiators is normally c.4 weeks. Please contact us for further details.

Download PDF Spec
